- Page 1 User Manual TP610P-4K Ultra-thin HDMI2.0 Extender 131ft/40m 4K UHD All Rights Reserved Version: TP610P-4K_2017V1.0...
- Page 2 1 x User Manual Introduction The TP610P-4K is an ultra-thin HDMI2.0 Extender consist of transmitter and receiver. It extends 1080p/4K HDMI signal over CAT5e/CAT6a cable up to 70m /40m (PoC), and enables IR and RS232 pass-through to control source or display device remotely. It also adopt a visually lossless video compression technology (VLC) to ensure the HD lossless transmission of HDR and 4K@60Hz/4:4:4 over CAT5e/CAT6a cable.
- Page 3 Connect to the HDBT IN socket on Receiver via CAT5e/6a cable. ⑦ HDBT IN (Receiver) Connect to the HDBT OUT socket on Transmitter CAT5e/6a cable. Support bi-directional PoC, either ports should be connected with ⑧ DC 12V Power Port 12V DC 2A power adaptor. Altimium www.altimium.com...
-
Page 4: System Diagram
Dimension (W*H*D) 115mm x 16 mm x 84mm Net Weight (g) Transmitter: 150g; Receiver: 153g System Diagram 4K 40m,1080P 70m CATx: HDMI: RS232: Power: Transmitter Receiver Emitter IR Emitter Receiver Receiver Laptop 4K Blu-Ray HDTV TV Remote Blu-Ray Remote Altimium www.altimium.com... - Page 5 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
