７．Other Cautions for Operation
7-1) Some of internal components of cylinder is made of iron. Protect them from direct splash of water
etc. If such a situation can't be avoided, contact SMC separately.
7-2) Before piping, perform flashing inside the piping to prevent intrusion of dust and cutting chip inside
the cylinder.
7-3) Do not give any damage including flaw and gouge on external face of cylinder tube. These damage
may be followed by the damage of soft wiper, packing and wearing and finally operating failure may
be caused.
８．Made to Order
The made to order of the rodless cylinder is available depending on operating environment and
conditions. The following shows relation between a certain operating environment or conditions and
applicable type of made to order.
Suffix
Heat resistant
－ＸＢ６
Low speed
－ＸＢ９
Long stroke
－ＸＢ１１
Low speed
－ＸＢ１３
Air hydraulic
－Ｘ１１６
With air supply port in
－Ｘ１３２
axial direction
High speed
－Ｘ１６０
With helisert screw
－Ｘ１６８
With additional
mounting screw hole
－Ｘ２０６
on external slider
Without external
－Ｘ２１０
lubrication
With hard chrome
plating on external face
－Ｘ３２２
of cylinder tube
Without external
lubrication
－Ｘ３２４
(with dust seal)
CY1B6 interchangeable
－Ｘ１４６８
specification
With a magnetic shield
－ＸＣ２４
plate
With floating joint
－ＸＣ５７
Spec. Operative environment and conditions
Suitable for the ambient temperature of
50 ℃ to 150 ℃.
The speed between 15 and 50mm/s is
required.
The stroke between 2001 and 3000 is
required.
The speed between 7 and 50mm/s is
required.
Intermediate stop accuracy higher
than one obtained by pneumatic
circuit is required.
The position of air supply port needs to
be changed in axial direction.
Operation at speed higher than
standard spec. is required.
(Speed without load: 1500mm/s)
Mounting screw of external slider
needs to be reinforced.
Mounting screw of external slider
needs to be added on the opposite of
standard side.
The grease is not needed on external
face of cylinder (for food and
industry and environment with
exposure to water/vapor).
Wear of external wearing needs to be
reduced (to improve durability of the
wearing).
The grease is not needed on external
face of cylinder (for food and
electronics industry and environment
with exposure to water/vapor)
For request to have the same mounting
dimensions as CY1B6.
For request to shield magnetic leakage
from an external slider.
The time to connect cylinder with
guide on other axis (load side) needs
to be reduced.
13
Applicable cylinder
tube I.D.
φ６～φ６３
φ６～φ６３
φ２５～φ６３
φ６～φ６３
φ２５～φ６３
φ６～φ６３
φ２０～φ６３
φ２０～φ６３
φ６～φ６３
φ６～φ６３
φ１５～φ６３
φ１０～φ６３
φ６
φ６～φ６３
φ６～φ６３
