Step 3 The main menu of the "Blue Gecko" App will open.
The "Blue Gecko" App consists of three demos se-
lectable from the main menu of the App:
• Health Thermometer
• Retail Beacon
• Key Fobs
The fourth option in the main menu of the "Blue
Gecko" App is called BLE Stack & Profile Test
which enables scanning for Bluetooth Smart devi-
ces. It lists the MAC Address, RSSI value and some
other details of the detected devices.
Before starting to test any of the demos using the
"Blue Gecko" App make sure that you have attach-
ed either the BGM111 or BGM113 Radio Board on
to the WSTK Main Board connectors and that you
have set up and switched on your WSTK Main
Board as instructed earlier in this guide.
The firmware inside the BGM111 / BGM113 module
on the Radio Board will default to the Health Ther-
mometer part of the demo after powering up the
WSTK Main Board.
2. Running the Health Thermometer Demo
Step 1 Select the Health Thermometer option from the
"Blue Gecko" App main menu.
Step 2 A screen opens up and your Blue Gecko device
(BGM111 or BGM113) should appear listed in the
DEVICE LIST.
Select your device (BGM111 or BGM113)
