Kommander-KA02 I
User Guide

Unpacking

Each K-array amplifier is built to the highest standard and
thoroughly inspected before leaving the factory.
Upon arrival, carefully inspect the shipping carton, then examine
and test your new amplifier. If you find any damage, immediately
notify the shipping company. Check that the following parts are
supplied with the product.
A. 1x Kommander-KA02 I amplifier unit
B. 2x Output channel flying connectors
two terminals Euroblock 2,5/ 2-ST-5,08
C. 1x Output channel flying connector
four terminals Euroblock 2,5/ 4-ST-5,08
D. 4x Balanced input flying connectors
three terminals Euroblock 1,5/ 3-ST-3,81
E. 1x Power supply with power cord
F. 1x The quick guide
A
B
C
D
Notes
** The AC mains cord plug may differ from the picture according to local regulation.
8
F
E
**

Kommander-KA02 I Rear Panel

1 2
10
1. 4x USB ports
2. RJ45 Ethernet port
3. 4 channels Euroblock 1,5/ 3-ST-3,81 balanced analog inputs
4. 3,5 mm jack unbalanced stereo analog input
5. Status LED
6. 4 channels Euroblock output terminals: speaker
connectors for either 2,5/ 2-ST-5,08 or 2,5/ 4-ST-5,08
flying plugs
7. Reset button
8. Optical S/P DIF stereo digital input
9. DC inlet
10. Power switch

Software

The dedicated K-array Connect app and the K-framework3
software for Mac and PC allow the user to access to the highly
configurable output section and the powerful DSP making any
Kommander-KA02 I amplifier a flexible driving unit.
click to go
3 4 5
9 8 7 6
WINDOWS and OSX software
K-framework3
click to go
