Discovery

1. Ensure that any amplifier units and the PC/Mac running
the K-framework3 are properly connected to the same
network.
2. Power up the Kommander-KA units.
3. Launch the K-framework3.
4. Open the Network window and launch the discovery:
• If the K-framework3 finds two or more devices with the
wrong ID, a dialog window appears where unique IDs can
be assigned to the units.
5. Once discovered, the real units are shown in the left
columns, following the order of their ID number; if the
workspace contains virtual devices of the same type you
can eventually modify the IDs in order to match the units
and allows the synchronization. The synchronization can
be in either directions: Workspace-to-Real or Real-to-
Workspace. Select the sync direction and synchronize all or
the single units separately
Kommander-KA02 I

Grouping

The working paradigm in the K-framework3 is to group the input
and output channels of the amplifiers on the workspace and
adjust the system performance within the groups.
Groups can be created working both off-line and on-line and are
retained by the real Kommander-KA units even once unplugged:
if a real device belongs to a group, the group is re-created on
the workspace during the synchronization process.
An active loudspeaker or amplifier might belong to multiple
groups sharing its features (eq filters, time delay, volume, etc).
The K-framework3 synchronization process reset
to default the EQ, delay and volume parameters
edited with the K-array Control mobile app and
the embedded Web app.
A. In Setup mode, set the Kommander-KA local parameters
(presets, routing, input gains, limiters, etc).
B. Add INPUT and OUTPUT
groups as needed.
C. Assign the amplifiers
units' channels to the
groups.
D. Switch to Tuning mode.
E. Align the system using
the tools available on the
groups (eq, delay, polarity,
etc).
