Unpacking; Azimut-Kamut2L1; Azimut-Kamut2V25; Azimut-Kamut2L14 - K-array Azimut Series User Manual

Azimut
User Guide
A. Lyzard-KZ1
B. Lyzard-KZ14
C. Vyper-KV25
D. Truffle-KTR24
E. Truffle-KTR25
F. Truffle-KTR26
G. Rumble-KU44-2
H. Kommander-KA02
5
4
3
6
H
16 15
4
A
B
C
2
7 8 9 10
14 13 12 11

Unpacking

D
Each K-array amplifier is built to the highest standard and
thoroughly inspected before leaving the factory. Upon arrival,
carefully inspect the shipping carton, then examine and test
your new amplifier. If you find any damage, immediately notify
E
the shipping company. Check that the following parts are
supplied with the product.

Azimut-KAMUT2L1

1x Kommander-KA02 amplifier
1x Truffle-KTR24 subwoofer
F 2x Lyzard-KZ1 ultra miniaturized
loudspeaker w/cable
1x Remote
1x Subwoofer cable
1x Power supply w/power cord
2x Line input connectors
(Phoenix MC 1.5/3-G-3.81)
3x Adhesive magnetic strip
G
3x Double-sided removable adhesive strip

Azimut-KAMUT2V25

1x Kommander-KA02 amplifier
1x Truffle-KTR26 subwoofer
2x Vyper-KV25 line-array element
1x Remote
1x Subwoofer cable
2x Loudspeaker cables
1x Power supply w/power cord
2x Line input connectors
(Phoenix MC 1.5/3-G-3.81)
4x Pairs of 3M Dual Lock pads
4x Wall mount brackets
1
1. Subwoofer cable
2. Vyper-KV25 cable
3. Brackets for Vyper-KV25
4. Balanced connection plugs
5. Wired loudspeaker plugs
6. Ethernet Port
7. USB ports
8. Optical input
9. 3,5 mm jack analog input

Azimut-KAMUT2L14

1x Kommander-KA02 amplifier
1x Truffle-KTR25 subwoofer
2x Lyzard-KZ14 ultra miniaturized
line-array element w/cable
1x Remote
1x Subwoofer cable
1x Power supply w/power cord
2x Line input connectors
(Phoenix MC 1.5/3-G-3.81)
3x Adhesive magnetic strip
3x Double-sided removable adhesive strip

Azimut-KAMUT2L

1x Kommander-KA02 amplifier
1x Rumble-KU44-2 subwoofer
2x Lyzard-KZ14 ultra miniaturized
line-array element w/cable
1x Remotee
1x Subwoofer cable
1x Power supply w/power cord
2x Line input connectors
(Phoenix MC 1.5/3-G-3.81)
3x Adhesive magnetic strip
3x Double-sided removable adhesive strip
10. Balanced analog inputs
11. Remote Control connector
*
12. Output connections
*
13. Wi-Fi reset switch
14. GPIO port
15. DC inlet
16. Power switch
* Available for Azimut-KAMUT2V25 only.
