ASSEMBLY INSTRUCTIONS
Quadro Loop leg 4 person
Corner workstation
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
STEP 04
C
Attach main desk beams (F) to legs (C) and Connector frame (E)
using nut insert in legs. See point attached
TOP VIEW
E
www.jasonl.com.au
Need help!
Call us on
1300 527 665
STEP 05
J
J
J
Frame looks like this. Using Allen Key, attach main desks beams (F)
with Socket (J)
J
J
J
J
J
