ASSEMBLY INSTRUCTIONS
Quadro Loop leg 4 person
Corner workstation
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
STEP 11
Using an Allen key remove top 4 caps from all screens uprights. Bring four partition towards one another and slide the 4 way
connector rod - down between the four screen uprights.
www.jasonl.com.au
Need help!
Call us on
1300 527 665
Page 15 of 15
