ASSEMBLY INSTRUCTIONS
Quadro Loop leg 4 person
Corner workstation
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
STEP 03
Adjust extendable main desk beans (F) to
desired length using markers and secure
beam at that length using screws provided
www.jasonl.com.au
Need help!
Call us on
1300 527 665
F
2000
1900
1800
1700
1600
1500
1400
1300
1200
50
50
Page 5 of 15
