- Page 1 ASSEMBLY INSTRUCTIONS Quadro Loop Boardroom table Sizes: 1800x1100 Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation www.jasonl.com.au Need help! 1 of 6 1300 527 665 Call us on...
- Page 2 ASSEMBLY INSTRUCTIONS Quadro Loop Boardroom table COMPONENTS Table top x1 Leg Quadro x2 Leg Quadro Loop x2 Beam x1 Plastic bracket x4 SCREWS M8x20MM CSK x2 M8x20MM Socket head x2 M6x20MM Socket head x4 M6x30mm Socket head x4 Allen key x2 Colour of the beam is always black, regardless desk frame colour.
- Page 3 ASSEMBLY INSTRUCTIONS Quadro Loop Boardroom table STEP 02 STEP 01 Using Allen Key provided, attach 2 plastic brackets per leg (E) (as per Using Allen Key provided, attach M8x20MM Socket head (G)- screw picture above) using M6x20MM (H) Socket head screw. Connect Loop socket half way into leg for both legs (B) Legs (C) to Bottom of Quadro Legs (B) by using 4 bolts per leg.
- Page 4 ASSEMBLY INSTRUCTIONS Quadro Loop Boardroom table STEP 03 Secure 1200mm beam (D) Adjust extendable beam to desired length using markers and secure beam at that length using screws provided 2000 1900 1800 1700 1600 1500 1400 1300 1200 www.jasonl.com.au Need help!
- Page 5 ASSEMBLY INSTRUCTIONS Quadro Loop Boardroom table STEP 05 STEP 04 TOP VIEW Attach beam (D) to legs (B) using nut insert in legs. Frame looks like this. Using Allen Key, attach beam (D) with Socket (F) See point attached www.jasonl.com.au...
- Page 6 ASSEMBLY INSTRUCTIONS Quadro Loop Boardroom table STEP 06 STEP 07 Place the desktop on top of the frame. Please place the legs ideally indent- Please tighten M6x30MM Socket head (I) through the ed around 300mm from each end left and right of the Tops, Place the legs plastic brackets into the underneath of the tops.
