ASSEMBLY INSTRUCTIONS
Quadro Loop leg 4 person
Corner workstation
Sizes: 1400Lx1800W , 1600Lx1800W , 1800Lx1800W mm
F
COMPONENTS
A Table top x4
B Table top Return x4
C Legs Quadro Loop x2
D Legs Quadro Loop Return x4
E Connector frame x1
F Beam: Main desk x4
G Beam: Return x4
H Plastic bracket x24
I Joiner plates x8
SCREWS
J M8x20MM CSK x12
K M8x20MM Socket head x12
L M6x20MM Socket head x24
M M6x30MM Socket head x24
N Join plates Screws x8
O Allen key x2
G
C
www.jasonl.com.au
Need help!
Call us on
1300 527 665
A
D
B
H
E
J K L M
Page 2 of 15
I
N
