Summary of Contents for Robam CXW-200-A810
- Page 1 Operation Manual 83 21 CXW-200-A810 CXW-200-A605 Range Hood...
-
Page 2: Table Of Contents
CONTENTS 1.Important Information......1 2.Product Overview.......1 3.Installation..........2 4.Use Instruction........6 5.Maintenance and Services....6 6.Circuit Diagram........9 7.General Troubleshooting....9... -
Page 3: Important Information
Range Hood Dear users: Thank for your buying our range hood. Please accept our best regards.Please read this operation manual carefully before installation and operation. *The pictures in this manual only for your reference. If the picture isn’t accord with object, subject to object. We keep to right to update appearance, structure or products without notice. - Page 4 Range Hood Size & Dimension Noise 55dB CXW-200-A810 Model CXW-200-A605 Rated input power of the hood A810:204W A605:203W Power Supply Rated input power of the main motor 220-240V~ 50Hz 200W × A810:≤2W 2 Total Pressure Efficiency ≥23% Maximum input power of the light ×...
-
Page 5: Installation
Range Hood Installation Warning 1.Flue gases shall not be discharged to the hot flue, which is exclusively used for discharging the combustion gas or other fuel fumes. 2.Note that when installing the metal expansion pipe, the pipe shall match perfectly with the hole in size. Overlarge hole is prohibited, as it will result in loose pipe and accidental drops. - Page 6 Range Hood Installation ● Determine the position: he size of removable baffle ( reference:430mm) can be adjusted according to the actual situations. The installation pitch of holes is shown in Figure2. The hook body shall be centered vertically and kept level. Ceiling hole size is shown in Figure3. The hood shall be installed upright the hob.
- Page 7 Range Hood ● Adjust the drawing panel: Pull the brackets of the panel up to an appropriate height and then pull the panel sides to find the drawing panel. Remove the protective film, and insert it along the gap between the decorative panel and the housing. Then adjust it to the proper height. ●...
-
Page 8: Use Instruction
Range Hood Use Instruction Switch Control Panel Switch control panel of A810 Plug in and three tick from the buzzer will indicate qualified installation. The hood is in standby. Press the power button, the light of "power "button turn on,press "high peed"... -
Page 9: Maintenance And Services
Range Hood Maintenance and Services Warning 1.There is a risk of fire if the appliance is not cleaned according to the methods stated in the instructions. 2.Cleaning and maintenance must be done when the power is disconnected. Keep the electrical components (e.g. motors, switches and connectors) away from water to avoid accidents. - Page 10 Range Hood Filter Mesh Removal Align the Phillips screwdriver wit the screw hole and raise Hold the two screws on the filter mesh and pull it down to it upward forcibly meanwhile rotating it counter- detach the two prongs inside from the exhaust fume clockwise about 120°, so as to remove the screw out of collecting hood.
-
Page 11: Circuit Diagram
Range Hood Circuit Diagram Circuit Diagram of A810 Yellow/ Green E 220-240V Terminal box 50Hz Brown Control circuit Blue Brown Blue Orange Black Gray Orange Black Yellow/ Green Brown Blue Yellow Blue Blue Circuit Diagram of A605 Yellow/ Green E 220-240V Mechanical button Brown... - Page 12 Edition: A/0...
