- Page 1 Operation Manual CXW-200-A812 CXW-200-A608 Range Hood...
-
Page 2: Table Of Contents
CONTENTS 1.Important Information ......2.Product Overview ........ 3.Packing list ........4. Installation ......... 5.Use Instruction ........6.Maintenance and Services ....7.Circuit Diagram ........8.General Troubleshooting ..... -
Page 3: Important Information
* The pictures in the manual for reference only. If pictures and actual are discrepancy, please see actual object. ROBAM keeps right to update structure or appearance without additional notice. Important Information New Package of Range Hood Please settle those packages carefully in order to protect environment. -
Page 4: Packing List
机 烟 油 吸 Range Hood Technical Parameter CXW-200-A812 ≤58dB Model Noise CXW-200-A608 220-240V~ 50Hz Rated Whole Machine Input Power 204W Power Supply Total Pressure Efficiency ≥23% Rated Main Motor Input Power 200W ≤4W Nominal Wind Pressure ≥220Pa Max Lighting Power... -
Page 5: Installation
吸油烟机 Range Hood Installation War ni ng The range hood is prohibited from exhausting fume into hot flue , which is used for exhausting gas fuel or other fuel fume. .When installing metal expansion tube, ensure perfect match of tube diameter with hole diameter to prevent accidental falling off from loosened expansion tube due to excessive hole expansion. - Page 6 机 烟 油 吸 Range Hood Installation ● (mm),but subject to adjustment Location:Reference dimension for installation of removable baffle is according to actual situations. The installation hole(picture ) shall be centered vertically with the hood body and kept horizontally. Please see picture for the installation size on the ceiling. Operator shall install range hood upright the gas hob with recommended lowest height between hood bottom mm (if maximum installation distance is specified in the instruction of installation, this shall be and cooktop is...
- Page 7 吸油烟机 Range Hood ● Install the hood body Fix the check valve as shown in Picture 5. Then direct the hanging holes in the back of hood at the hooks of hitching foots according to Picture 2, and press them together. Shake the body to check if it's hung securely. After the body is mounted, install the hitching foot stopper and gaskets to the M6 metal expansion pipe, and then tighten the nuts (to prevent accidental decoupling of the body under external force).
-
Page 8: Use Instruction
机 烟 油 吸 Range Hood Use Instruction Switch Control Panel Light High Power Auto Plug in and 3 tick from the buzzer will indicate qualified installation. The hood is in standby. ●Press the light button to turn on the light and repress to turn it off. Light ●... -
Page 9: Maintenance And Services
吸油烟机 Range Hood Maintenance and Service Warning 1.There is a risk of fire if the appliance is not cleaned according to the methods stated in the instructions. 2. Cleaning and maintenance must be done when the power is disconnected. Keep the electrical components (e.g. - Page 10 机 烟 油 吸 Range Hood Gas sensor and heat sensor removal ● Use a Phillips screwdriver to remove the heat sensor two screws on the gas sensor and heat sensor, then replace it. gas sensor General Plan of Body Installation and Removal 1.
-
Page 11: Circuit Diagram
吸油烟机 Range Hood Circuit Diagram Yellow/Green E Terminal box brown 220-240V~ Control circuit blue blue black Yellow/Green orange brown yellow blue Warning There shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels. - Page 12 Edition: A/2...
