1.2 Sysrem structure
This system mainly consists of a PLC, master unit, N4E0-T7EC mounted manifold solenoid valve, and
peripheral equipment (EtherCAT slave units).
1) Examples of PLC and master unit combination
PLC manufacturer
Omron Corporation
Beckhoff Automation GmbH & Co. KG
2) Example of basic structure of the system
Master
unit
Other master units compatible with EtherCAT
PLC
IN
OUT
N4E0-T7EC mounted
manifold solenoid valve
Compatible PLC
NJ Series
TwinCAT PLC
EtherCAT network
EtherCAT slave units
−6−
1
PRODUCT
Master unit model
NJ301/NJ501
[SM-P00081-A]
