Changing The Transmission Fluid; Adjusting The Maximum Speed Range - Toro Revolution Series Operator's Manual

Changing the Transmission
Fluid
Service Interval: After the first 50 hours
Every 500 hours
Fluid type: Toro Synthetic Electric Motor Drive Oil
Capacity: 150 mL (5 fl oz)
1. Park the machine on a level surface, disengage
the PTO, and move the motion-control levers
outward to the P
ARK
2. Shut off the machine, remove the key, and wait
for all moving parts to stop before leaving the
operating position.
3. Remove the tire.
Figure 61
4. Place a drain pan under the transmission.
5. Remove the top plug and bottom plug. Allow
the fluid to drain.
Figure 62
position.
6. Install the bottom plug and torque it to 7 to 8
N∙m (62 to 70 in-lb).
7. Remove a side plug.
8. Add fluid, as specified at the beginning of this
procedure, through the top hole until the level
reaches the side plug opening.
9. Install the top plug and side plug . Torque them
to 7 to 8 N∙m (62 to 70 in-lb).
10. Install the tire and torque the lug nuts to 75 to
88 N∙m (55 to 65 ft-lb).
11. Repeat for the other transmission.
Adjusting the Maximum
Speed Range
Note:
The InfoCenter displays only 2 items at a time;
g409011
however, the following figures show the full menus
for context.
1. Park the machine on a level surface, disengage
the PTO, and move the motion-control levers
outward to the P
2. Enable access to protected menus; refer to
Accessing Protected Menus (page
3. In the M
AIN MENU
press the
g380054
42
Figure 63
position.
ARK
17).
, scroll down to S
ERVICE
button .
Figure 64
g380053
and
