SUGATSUNE LAMP FD50-H Installation Manual

FD50-H SLIDING DOOR SYSTEM
(Surface Mount Roller, Standard Sliding)
Thank you for using our product. Before installation, please read this manual thoroughly to ensure correct installation.
Please keep this manual at hand for future reference.

ABOUT THE PRODUCT

This product is a parts set for a sliding door system for
●
residential & commercial use.
● The door can be installed without the use of tools.

SPECIFICATIONS

Door height
Door width
Min. Door thickness
Max. Door weight
Vertical adjustment

FOR YOUR SAFETY AND CORRECT INSTALLATION

Meaning of symbols
Warning
Prohibited
Caution
WARNING:
If not followed, death or serious injury may result.
This product should be installed by a qualified person in accordance with this manual. If it is not installed correctly, the door
may fall and cause injury.
Provide a frame that can withstand the weight and impact of opening and closing the door. Be sure to use the specified
screws and tighten them securely. If the mounting strength is insufficient, the door may fall and cause injury.
Do not try to use this product for anything other than its original purpose. Do not use any part for applications outside of its
specification.
Do not disassemble or modify any parts other than those described in this document.
Caution:
If not followed, injury or damage may result.
Follow the specified dimensions, specifications, and alignment of the door and frame. Warping, tilting or twisting of the
frame or door may cause failure.
If cutting any parts, make sure to remove any burrs before installation. Also check the upper track for any left-over burrs or
scraps and remove these.
This product is a part for architectural fittings. After installation, please check the function and safety of the final product.
Please inform the end user how to use the product safely.
Make sure to check the screws for slack at regular intervals (one month from first usage, half a year, and then one time
every year is recommended).
Max. 2400 mm
2401 ‑ 2700mm
774 ‑ 1500mm 800 ‑ 1500mm
30 mm
50 kg / door
± 4 mm
Required
Installation Manual
Part No.FD50HMP
