CKD CHV2 Instruction Manual page 7

4. INTERNAL STRUCTURE AND LISTS OF PARTS
1 2
No.
1
2
3
4
5
6
7
8
Materials shown in ( ) are used when designating the option "A" (fluoro rubber
specifications).
3 4 5 6
Name of parts
Cover A
O ring
Tube
Valving element
Valve guide
Coil spring
Cover B
O ring
7 1 2
Materials
Aluminum alloy
Nitrile rubber (Fluoro rubber)
Aluminum alloy
Nitrile rubber (Fluoro rubber)
Polyacetal resin
Stainless steel
Aluminum alloy
Nitrile rubber (Fluoro rubber)
−6−
INTERNAL
STRUCTURE
3 8 5 6
[SM‑315295‑A]
４
7
