INSTALLATION: TOE-KICK & AIR INTAKE GRILLE REMOVAL / DISCONNECTING CASE FROM SKID
1. Disconnect Case From Skid
Use Phillips driver to remove screws from
shipping brackets. Remove and discard
shipping brackets from skid.
J-Bar
Rubber
Shipping Block
Shipping
Bracket

Skid

Pry Bar
6
Place J-bar/pry bar under base frame. Raise case
up from skid to take weight off casters.
With case raised, lower casters all the way down
against skid (see next step for detailed instructions
on lowering or raising casters).
Remove rubber shipping blocks.
Shipping
Bracket
Rubber
Shipping Block
