CASE DESIGN, CONT'D: CONDENSER PACKAGE (SELF-CONTAINED UNITS ONLY)

9. Condenser Package (Self-Contained Units Only)
Assembly/disassembly and servicing to be performed by licensed refrigeration contractor.
Condensate Package Configuration
• Illustration below may not reflect every feature or option of your particular condenser package.
Note: Model NM4855RSSV (Shown) Is
Similar To Model NM7255RSSV. However,
It May Not Reflect Every Feature Or
Option Of Your Particular Case.
Optional Clean Sweep®
Controller DC
Condenser Coil
Condenser Coil
Condenser Coil
Driver
Housing
Fans & Motors
Cleaning System
Refrigeration
U-Tubes
Filter Dryer
Overflow
Condensate Pan
(With Electric Coil)
Compressor
Hot Gas Loop
Sight
Electrical
Condensate Pan
Glass
Starter Unit
