CASE DESIGN, CONT'D: REAR VIEW OF MODEL NM4855RSS SELF-SERVICE MERCHANDISER
2. Rear View Of Model NM4855RSSV Self-Service Merchandisers
• Model illustrated below may not reflect every feature or option of your particular merchandiser.
• Single end panel is shown.
• Lineup will determine end panel configuration.
• See previous page for front view of merchandiser.
Casters (Typ.)
Solid Back Rear
Condenser
Note: Do Not Remove This Shipping
Package
Brace (As It Is Opposite Condenser
Package Access Side Of Case).
Note: Model NM4855RSSV (Shown)
May Not Reflect Every Feature Or
Option Of Your Particular Case.
Panel
13
End Panel On Certain
Lineup Models
(Not End Caps)
Casters (Typ.)
