CASE DESIGN: FRONT VIEW OF MODEL NM4855RSS SELF-SERVICE MERCHANDISER

1. Front View Of Model NM4855RSSV Self-Service Merchandisers
• Partially disassembled model illustrated below may not reflect every feature or option of your particular

merchandiser.

• Single end panel is shown.
• Lineup will determine end panel configuration.
• See next page for rear view of merchandiser.
Thermometer
Shelving
Thermostat
Sensor
Cover
Handles For
Pushing or
Pulling Unit Into
Position
Casters (Typ.)
Shipping Brace To
Remain on Case
Air Discharge
Chimney
Thermostat and
Main Power Switch
12
Note: Model NM4855RSSV (Shown)
May Not Reflect Every Feature Or
Option Of Your Particular Case.
Deck Pans
Honeycomb
Air Diffuser
Solid Back
Rear Panels
Right End
Panel
Air Return
Acrylic Air
Deflector
Condenser
Package /
Clean Sweep
Coil Cleaner
