Portable TV Tripod
Instruction Manual
SKU: STAND-TV55T/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv55t
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-TV55T/W
Summary of Contents for Vivo STAND-TV55T/W
- Page 1 Portable TV Tripod Instruction Manual SKU: STAND-TV55T/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv55t GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 ASSEMBLY STEPS STEP 1 Unfold Tripod Base (A) and tighten the lower knob. STEP 2 Loosen the upper knob on the pole of Tripod Base (A), adjust the pole to the desired height, insert the retainer pin, then tighten the upper knob.
- Page 4 STEP 3 Install Mounting Bracket (E) using M6x50mm Carriage Bolts (S-A), Metal Washers (S-D) and M6 Lock Nuts (S-B). The arrow on Mounting Bracket (E) must be pointing up. Tighten with Wrench (T-A). STEP 4 Assemble VESA Plate (B) to Mounting Bracket (E) using M6x14mm Screws (S-E), Metal Washers (S-D), Plastic Washers (S-C) and M6 Lock Nuts (S-B).
- Page 5 STEP 5 OPTION A: Small TV Mount VESA Brackets (C, D) to the back of the TV with Screws (M-A through M-D) and M8 Washers (M-E). Spacers (M-F, M-G) may be required. Tighten with a Phillips screwdriver.
- Page 6 STEP 6 Hang the TV with VESA Brackets (C, D) over the VESA Plate (B) and secure with the pre-installed bolts underneath using a Phillips screwdriver.
- Page 7 Adjust as Desired...
