  • Page 1 Operation and Service Manual Operation Service Manual ABG Series Battery Powered Nutrunners...
  • Page 2: Table Of Contents

    We therefore suggest that you read these operating and service instructions carefully and observe the following: Technical Data The ABG Nutrunner and the supplied Battery Charger may only Safety instructions be serviced and repaired by authorized AIMCO service Intended Use personnel. Operators Responsibilities Hazard Notices...
  • Page 3: Incoming Inspection And Packaging

    Operation and Service Manual Incoming Inspection and Packaging High Performance Li-Ion Rechargeable Battery Pack The product is shipped with the following: One (1) AcraDyne ABG Battery-Powered Nutrunner, two (2) high-performance Li-ion rechargeable battery packs, and one (1) AcraDyne charger station. All parts must be visually inspected for possible transport damages.
  • Page 4: Technical Data

    ABG Battery-Powered Nutrunners Technical Data Accessories AcraDyne Li-Ion rechargeable battery pack: Voltage 18 V, 5.2 Ah Charging time approx. 100 min. AcraDyne charger station: 220-240 V / 50-60 Hz / 65 W Output 12-42 V / 3.0 A max (optional 110 V / 50 Hz) Safety Instructions Intended Use The AcraDyne ABG Nutrunner has been designed for...
  • Page 5: Hazard Notices

    Operation and Service Manual Hazard notices Operating the Charger Station The charger station must only be used if the mains In case of mechanical or electrical damages to the Li-Ion electrical supply matches the voltage and frequency battery pack or the charger station, the use of the specifications on the charger label.
  • Page 6: Operating The Acradyne Abg Nutrunner

    ABG Battery-Powered Nutrunners Operating the AcraDyne ABG Nutrunner 4.1.2 Battery Pack, Capacity, and Signal Display* The ABG Nutrunner must not be damp or wet, and may not be used in a damp or humid environment. Always provide rain protection. Before first use, always fully charge the battery pack.
  • Page 7: Preparing For Work With The Power Tool

    Operation and Service Manual Preparing for Work with the Power Tool Before preparing the power tool for work remove the Li-Ion battery pack from the tool. Depending on the specific job, various adapters for tightening and loosening of bolted connections are needed. •...
  • Page 8: Direction Of Rotation, Transport Lock

    Setting the torque is done by means of the torque table on the tool or according to the standard torque chart included. Machine-specific torque values can be compiled and Direction right (clockwise, documented on request by the AIMCO calibration tightening). Push the slide lab. switch completely to the left.
  • Page 9: Mechanical Operation

    Always place the socket/connector completely and safely on the bolt/nut. The support of the reaction bar to absorb the reaction torque must always be safe and stable. Please consult your AIMCO partner for customized reaction bar solutions. An incomplete or incorrect connection or support will lead to the following when bolting: •...
  • Page 10: Function And Operation Test

    Please send all devices to be repaired in In order to maintain the battery pack in a fully charged their original packaging to your nearest AIMCO state, a trickle charge of about 70 to 75% is required partner.
  • Page 11: Technical Notes

    Operation and Service Manual Technical Notes Excessive temperature Overheating of the power tool over an extended period of time Safety Shut-Off will result in temperature switch-off. The tool or the battery pack must be cooled down. In order to prevent faulty boltings or damages to the power tool, the AcraDyne AGB Nutrunner is fitted If the battery pack is very warm to the touch, it is with a multi-functional monitoring system.
