- Page 1 Quick Start Guide One Too Moment Alpha Torque Wrench PO Box 16460, Portland OR 97292-0460 1-800-852-1368 • (503) 254-6600 www.aimco-global.com...
- Page 2 Image 1 shows the ‘main screen and when selecting the menu button or select sequence, operator will navigate back to the main screen by using the return arrow symbol embedded into the controller/tablet Touch Screen to Menu activate analyzer button www.aimco-global.com • (800) 852-1368 • (503) 254-6600...
- Page 3 Sequence Setup screen. 2. Touch the pencil icon, which takes you to the User name screen. 3. Log in using default user name and password. Default User Name: admin Default Password: admin www.aimco-global.com • (800) 852-1368 • (503) 254-6600...
- Page 4 • Target Angle • Residual Torque Select the appropriate program. You can develop more than one program per strategy. 3. Use return arrow key to save sequence/ program and return to the main screen. www.aimco-global.com • (800) 852-1368 • (503) 254-6600...
- Page 5 2. Populate program parameters with the following required details: • Target Torque (min/max will default to 10% of target) • Min/Max Angle • Batch Count Other inputs are optional and will influence test results. www.aimco-global.com • (800) 852-1368 • (503) 254-6600...
- Page 6 Edits to the program can be made: • Reset target torque • Refine the min/max torque window • Refine the angle window • Adjust the batch count Additional edits are available as well. See LIT-MAN271 for more options. www.aimco-global.com • (800) 852-1368 • (503) 254-6600...
- Page 7 Touch the menu tab. Select the Last results. View rundowns • Production (tightening) • Quality View Traces Touch the menu tab. Select Last Curves. Use return arrow key to return to the main screen. www.aimco-global.com • (800) 852-1368 • (503) 254-6600...
- Page 8 Toll Free: 1-800-852-1368 Phone: 0086-21-34319246 Phone: 0082-2-2054-8930 Fax: 0086-21-34319245 Cell: 0082 10 9804 8905 WWW.AIMCO-GLOBAL.COM AIMCO CORPORATION DE MEXICO SA DE CV AIMCO SOUTH AMERICA AIMCO EUROPE Ave. Cristobal Colon 14529 Calle Congreve No 800. Escobar Dibao Plaza Avenida Río Gallo, 431 Chihuahua, Chihuahua.
