- Page 1 C C O O R R D D L L E E S S S S T T O O O O L L S S O O P P E E R R A A T T I I O O N N S S M M A A N N U U A A L L...
- Page 2 P P I I S S T T O O L L M M O O D D E E L L...
- Page 3 A A N N G G L L E E M M O O D D E E L L...
- Page 4 Thank you for your purchase of a Signature Series Precision Clutch Cordless Tool from AIMCO. The Signature Series follows the concept of PERQ ™ adding to your company’s Productivity, Reliability, Ergonomics and Quality demands as part of the most compre- hensive line of assembly tools available from a single source worldwide.
- Page 5 Should the overtemperature circuit be activated repeatedly in a short time, the tool should be examined by an authorized AIMCO Signature Series repair center. As with any electric tool, overheating may be caused by use in excess of its duty cycle.
- Page 6 Torque Adjustment: Pistol Models (SPC-P-2, SPC-P-4, SPC-P-6, SPC-P-9, SPC-P-9H) Requires use of supplied Adjustment Tool (L) Run tool on Torque Tester, such as Auditor ®...
- Page 7 To start the fastening cycle, depress the trigger completely (H on Pistol Model Tools, F on Right Angle Model Tools) To activate the LED lights only, depress the trigger halfway (H on Pistol Model Tools, F on Right Angle Model Tools) R R O O T T A A T T I I O O N N S S E E L L E E C C T T I I O O N N S S W W I I T T C C H H To change the direction of rotation, simply depress the rotation direction switch.
-
Page 8: Pistol Model Diagram
The Signature Series battery charger requires an adapter to accept both the 9.6V and 12V batteries in NiCad or NiMH types (J on Pistol Model Diagram, same adapter for all types of tools). The supplied adapter fits all Signature Series batteries. Be sure that the adapter is installed onto the charger prior to attempting to charge the battery. -
Page 9: Accessories
Visually inspect the tool housing to insure that no cracks or degradation of the ma- terial is evident. Should cracking or deep abrasion be noted, please send the tool to an authorized AIMCO Signature Series service center for estimate and repair. Lubrication of the gearbox is recommended after the installation of 250,000 fasteners with the tool. -
Page 10: Repaired Tool Warranty
This Warranty is null and void if the customer, or any other person other than an authorized representative of AIMCO, has made any attempt to service or modify the tool or accessory prior to its return to AIMCO under this Warranty. - Page 11 AIMCO'S LIABILITY PURSUANT TO WARRANTY OF THE PRODUCTS COVERED HEREUNDER IS LIMITED TO REFUND OF THE PURCHASE PRICE. IN NO EVENT SHALL AIMCO BE LIABLE FOR COSTS OF PROCUREMENT OF SUBSTITUTE GOODS BY THE BUYER. IN NO EVENT SHALL AIMCO...
- Page 12 . . a a i i m m c c o o - - g g l l o o b b a a l l . . c c o o m m LIT-MAN250, Rev.12/06 Printed in USA ©2006 AIMCO...
