- Page 1 AcraDyne Gen III 3000 Series Nutrunners Operations Manual PO Box 16460, Portland OR 97292-0460 • 800-852-1368 • Fax 800-582-9015 www.aimco-global.com...
-
Page 2: Safety Information
Introduction Thank you for purchasing this AcraDyne DC electric assembly tool, one of the lightest and fastest DC elec- tric assembly tools on the market. When used with the AcraDyne iEC tool controller, this tool will provide excellent productivity, ergonomics, reliability and quality on a wide range of industrial assembly applica- tions. -
Page 3: Operation
OPERATION Cable Multi Function Angle Head Tool Body Connection Button Square/ Start Lever Hex Drive 1. Connect tool cable to the iEC controller and the tool: underway. Pressing the MFB will cause the tool to flash yel- The tool cable has curved alignment tabs and slots built into low and red LED lights. - Page 4 GEN III 3000 SERIES ANGLE NUTRUNNERS PAGE HEADER HERE Assembly for: AEN33060A and AEN33090A ITEM # QTY. PART # DESCRIPTION 33060A 33090A 25057 NUTRUNNER HOUSING, G1-3K 25525 MOTOR ASSY, 9T, 3000 SERIES 25063 LED BOARD ASM. 25075 SCREW, SHC 4-40X.375, STEEL, BLACK OXIDE 25430 STAND-OFF, LED, 3000 SERIES 25073...
- Page 5 GEN III 3000 SERIES ANGLE NUTRUNNERS PAGE HEADER HERE Assembly for: AEN33120A ITEM # QTY. PART # DESCRIPTION 33120A 25057 NUTRUNNER HOUSING, G1-3K 25525 MOTOR ASSY, 9T, 3000 SERIES 25063 LED BOARD ASM. 25075 SCREW, SHC 4-40X.375, STEEL, BLACK OXIDE 25430 STAND-OFF, LED, 3000 SERIES 25073...
- Page 6 GEN III 3000 SERIES ANGLE NUTRUNNERS PAGE HEADER HERE Assembly for: AEN33200A, AEN33300A and AEN33450A ITEM # QTY. PART # DESCRIPTION 33200A 33300A 33450A 25057 NUTRUNNER HOUSING, G1-3K 25530 MOTOR / ID BOARD ASSY, 15 T, 3000 SERIES 25063 LED BOARD ASM. 25075 SCREW, SHC 4-40X.375, STEEL, BLACK OXIDE 25430...
- Page 7 GEN III 3000 SERIES IN-LINE NUTRUNNERS PAGE HEADER HERE Assembly for: AES33040A and AES33060A ITEM # QTY. PART # DESCRIPTION 33040A 33060A 25057 NUTRUNNER HOUSING, G1-3K 25525 MOTOR ASSY, 9T, 3000 SERIES 25063 LED BOARD ASM. 25075 SCREW, SHC 4-40X.375, STEEL, BLACK OXIDE 25430 STAND-OFF, LED, 3000 SERIES 25073...
- Page 8 GEN III 3000 SERIES IN-LINE NUTRUNNERS PAGE HEADER HERE Assembly for: AES33100A, AES33150A and AES33230A ITEM # QTY. PART # DESCRIPTION 33100A 33150A 33230A 25057 NUTRUNNER HOUSING, G1-3K 25530 MOTOR / ID BOARD ASSY, 15 T, 3000 SERIES 25063 LED BOARD ASM. 25075 SCREW, SHC 4-40X.375, STEEL, BLACK OXIDE 25430...
- Page 9 GEN III 3000 SERIES IN-LINE NUTRUNNERS PAGE HEADER HERE Assembly for: AES33400A and AES33600A ITEM # QTY. PART # DESCRIPTION 33400A 33600A 25057 NUTRUNNER HOUSING, G1-3K 25530 MOTOR / ID BOARD ASSY, 15 T, 3000 SERIES 25063 LED BOARD ASM. 25075 SCREW, SHC 4-40X.375, STEEL, BLACK OXIDE 25430...
-
Page 10: Specifications
Specifications Environmental • Operating Temperature: 0°C to 32°C • Storage Temperature: 0°C to 65°C • Humidity: 5% to 90% RH, Non-Condensing, for temperatures 0°C to 40°C 5% to 60% RH, Non-Condensing, for temperatures 0°C to 65°C • Maximum Altitude of Operation: 3000m •... - Page 11 NOTES...
- Page 12 AIMCO CORPORATE HEADQUARTERS AIMCO CORPORATION DE MEXICO SA DE CV 10000 SE Pine Street Ave. Cristobal Colon 14529 Portland, Oregon 97216 Chihuahua, Chihuahua. 31125 Phone: (503) 254–6600 Mexico Toll Free: 1-800-852-1368 Phone: (01-614) 380-1010 Fax: (01-614) 380-1019 LIT-MAN160 Rev. 07/2020...
