Access Modular Controller 2
11.2.2 Firmware until 6x.45, 37.60
Push
0
1
2
3
4
4a
4b
4c
5
6
7
8
9
10
11
12
13
14
Bosch Security Systems B.V.
Display (Example)
Vaa.bb 01.05.17
S/N1: 0910024419
S/N2: 22850034
11.18 12:24:18 S
Dig. IO: ::::::::::::::::
Dig. I1: ::::::::::::::::
Dig. I2: ::::::::::::::::
Dig. I3: ::::::::::::::::
MAC 001B860012AB
N AMC-1234-5678
I 192.168.10.18
G 192.168.10.255
M 255.255.255.0
H 192.168.10.10
DHCP 1
D 192.168.10.1
Host: + "C"
HSC state: x
Руководство по установке
Description
aa = Reader Protocol Version
37 - Wiegand, 60 - Lbus, 61 - BG900, 62 - OSDP
bb = Firmware Version
01.05.17 release date of the firmware (dd.mm.yy)
Serial number 18 digits - Part1 10 digits
Part 2 - 8 digits
Current date and time (MM.DD hh:mm:ss)
(S) = daylight saving
Display of the digital contacts: the input signals set will
be shown with an extension above - output signals with
an extension below. The first eight digits display the
controller's signals. The second eight digits display the
extension board's signals
If there are I/O-Boards connected, the signals will
be shown on separate pages.
Network device address (MAC)
Network name of the controller (max. 14 char.)
See Configuring Ethernet interface, page 32 .
IP-address of the controller
IP-address of the gateway
Subnetmask
IP-address of the host computer
DHCP-status:
1 = on
0 = off
IP-address of the DNS server
Host activity:
+ = online
- = offline
"C" = Counter (0 to 9) of the received data packages
from the host interface.
RS-485 Bus connection:
A = Address 1 ... H = Address 8
Host secure status:
1 = enable
2 = disable
