Plastic cable ties
Diagonal wire cutters
Telephone cable insulation strippers
Punchdown tool matching all PBX termination blocks used at installation site
1
# T10 Torx driver
Level
Drill
#1 and #2 Phillips screwdrivers
Wire strippers (capable to strip 24 AWG
Long-nosed pliers
1.3

System Capacities

KWS500:
(Central Control Unit/
1.9 GHz Base Station)
KIRK Handsets supported:
• KIRK 3040
• KIRK 4020/4040
• KIRK 5020
Simultaneous voice
conversations:
KIRK Repeaters
(optional):
punchdown termination block. Wires connected to the other side of the termination block travel to
PBX extensions and to the KWS500's spring-loaded termination block.
Used to push a telephone wire down into a slot on a termination (punchdown) block.
1
Abbreviation for American Wire Gauge, a standard system for measuring the diameter of
2
electrical wire. The number of the gauge is determined by the number of successively smaller dies
the wire is drawn through. Thus a 24 gauge wire is much thinner than a 10 gauge wire.
Two-way radio unit placed within the range of a base station that can pick up and retransmit a
3
base station's or wireless telephone's signal. Repeaters can be used to expand the system's
coverage area.
)
2
1
8
6
6
supported
3
KIRK Wireless Server 500 User Guide
