signal
8323
cabinet
Component List
A - Phillips Screwdriver
B - Hex Driver
C - Assembled Cabinet
D - 1/4-20 x 1"
E - Leg
F - M4 x 25mm Screw
G - Pull
H - Adjustable Shelf
I - Back Panel x 2
J - Cardboard Corner
Designed by Noah Packard.
international patents, trade dress, and/or copyright laws.
BDI are trademarks of Becker Designed, Inc.
All Rights reserved. ©2012, BDI
Made in China. 8323_8329REV112114v4
8329
AND
Signal is engineered for easy assembly. Carefully follow this
procedure to prevent any damage.
x 1
Don't discard packaging until reading these instructions.
NOTE: This instruction sheet is intended for the entire Signal
x 1
collection; model 8329 is shown for illustration.
Placement and Maintenance
x 1
Signal is designed for indoor use on level floors. Clean steel parts
and wood veneer with a moist cloth. Many wood surfaces are
subject to fading under direct sunlight. BDI's unique Graphite finish
has properties that make it more sensitive than others. Please avoid
placing BDI's Graphite finish in direct sunlight.
Machine Screw
x 6
Step 1
Unpack and Identify
x 2
Unpack and identify the components at left. Note that some
components are shipped inside the cabinet. The assembly
workspace should be a non-marring surface such as carpet. For
missing hardware pieces, please contact BDI Customer Service
x 4
at customerservice@bdiusa.com. For all other concerns, please
contact your BDI Retailer.
x 2
Step 2
Remove Cardboard Corner Protectors (J) from packaging.
x 2
Protector
x 2
a s s e m b l y i n s t r u c t i o n s
bdiusa.com
J
1
customerservice@bdiusa.com
