２.３

Preparation of necessary supplies

Please prepare the following items for installation and wiring.
・Wiring cable
・M4 screw
・ Cable with crimping terminal
・Toothed washer
・Switch (24 VDC, contact capacity of 0.5 A or more)：For lock release
Please provide the following equipment to run the system.
・24 VDC power supply
・ PC
・PLC
■
Electrical Wiring Specifications
Prepare the wiring according to the following specifications (to be prepared by the user).
Item
Applicable wire size
Single, stranded wire --> AWG20（0.5mm
The rated temperature of the insulation coating should be 60
The O.D. should be ø2.5 mm or less.
- 31 -
Specification
）
2
o
C or more.
