2.
Fasten the thermostat:
•
Drive the screws through the holes in the bottom
corners of the thermostat.
•
Seal the holes with the enclosed screw stopper to
maintain the density.
3.
Connect the thermostat according to the connection
diagram.
•
Heating: (L-main, N-main, L-load, NO (normally open)
- load).
•
Cooling: (L-main, N-main, L-load, NC (normally closed)
- load).
8
D610
L
N
N NO NC
L
Mains
Max.Load
220-240V~
10 (1) A
N
IP44
-10T50
NTC
DEVIreg™ 610
Installation Guide
