Bulb Replacement

1. Turn off power and gas to unit and allow to cool to room temperature.
2. Remove outer safety glass panels and inner panels (firebox glass)–see
instructions in this manual.
Light are located behind the front face of the unit
3. Loosen 2 outer screws on each side to remove outer light cover — located
in the upper inside front of the firebox..
Outer light covers shown from back of unit (back made transparent)
4. Lift outer light covers up off tabs to remove.
Tab
| City Series CV72E-12
26
5. Loosen 2 screws on each side of individual inner light cover and remove.
6. Replace bulb and reverse steps to complete procedure.
NOTE: Do not handle bulb with bare hands. Use packaging or a tissue to hold
Regency Part# 911-208 Oven Lamp Assembly G9 120V/25W
Regency Part# 911-072 Replacement Bulb G9 120 Volt/25 watt
t t o o o o l l t t i i p p
new bulb when replacing.
Inner Light Covers
Inner light covers shown from back of unit (back made transparent)
