Firmware Upgrade With Mitel Border Gateway 10.1.0.2Xx; Reboot Phone - Mitel MiVoice 6900 Series Manual

W UI F
EB EATURES
systemctl start xftftpserver
–
Reboot the Mitel 6970 IP Conference Phone.
12.
: TFTP server must not be specified in Network settings.
NOTE

Firmware upgrade with Mitel Border Gateway 10.1.0.2xx

On SWDL, go to MiVoice Business > 6970 IP Conference Firmware > 6970 FW 1.4.1.51.
1.
Download the following rpm package:
2.
mitel-phoneloads-6970-1.4.1.51-1.noarch.rpm
–
Connect to your MBG server using the SCP client on your PC (for example, WinSCP). Select SFTP
3.
as a protocol.
Copy the .rpm file from your PC to the /tmp directory on the server.
4.
Connect to MBG using the SSH client on your PC.
5.
Run the following commands to apply firmware:
6.
cd /tmp
–
rpm -Uvh mitel-phoneloads-6970- xxx.noarch.rpm
–
Run the following command to verify the correct installation of .rpm package:
7.
rpm -qa | grep mitel-phoneloads-6970
–
Ensure that the specified mitel-phoneloads-6970- xxx.noarch.rpm file is present in the output list.
Reboot the MBG server using Mitel Web UI:
8.
Open Mitel Web UI in your browser.
–
In the address bar, type the MBG IP address.
–
Navigate to Administration > Shutdown or reconfigure.
–
Select Reboot and then click the Perform button.
–
Reboot the Mitel 6970 IP Conference Phone.
9.
: TFTP server must not be specified in Network settings.
NOTE

Reboot Phone

The Reboot Phone option on the Mitel Web UI allows you to remotely reboot the respective Mitel MiVoice
6900 Series IP phone.
To reboot the respective IP phone:
Open your web browser and enter the phone's IP address or host name into the address bar.
1.
Enter your username and password and click OK/Login.
2.
The status window displays for the IP phone you are accessing.
: The default username is "root" and the default password is "73738".
NOTE
Click on Reboot Phone.
3.
R P
EBOOT HONE
78
