Pole Mount Pneumatic Arm Laptop Holder
Instruction Manual
SKU: MOUNT-POLE05L
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-pole05l
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOUNT-POLE05L and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo MOUNT-POLE05L

  • Page 1 Pole Mount Pneumatic Arm Laptop Holder Instruction Manual SKU: MOUNT-POLE05L Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-pole05l GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 ASSEMBLY STEPS STEP 1 While holding Arm (A) closed, cut the shipping tie and gently open Arm (A). STEP 2 (Option A) 28-45mm Pole Diameter: For poles with a diameter of 28-45mm, assemble Arm (A) to the pole using Bracket (B) and M8x50mm Screws (S-A) with M8 Nuts (S-C).
  • Page 4 STEP 2 (Option B) 46-60mm Pole Diameter: For poles with a diameter of 46-60mm, assemble Arm (A) to the pole using Bracket (B) and M8x65mm Screws (S-B) with M8 Nuts (S-C). Tighten screws using 5mm Allen Wrench (T-B). STEP 3 Install Laptop Tray Arms (D) to Laptop Tray (C) using Clips (E).
  • Page 5 STEP 4 Insert M4x8mm Screws (S-D) into the top two holes of Laptop Tray (C) using the Phillips end of 4mm Allen Wrench (T-A), leaving atleast 3mm of threads exposed. Slide installed M4x8mm Screws (S-D) into the slots in the VESA plate on Arm (A). Install remaining M4x8mm Screws (S-D) into the lower holes of Laptop Tray (C).
  • Page 6 STEP 5 Adjust the tension in Arm (A) using 5mm Allen Wrench (T-B). STEP 6 Flip the stoppers on Laptop Tray (C) to prevent the laptop from sliding down. Unlock the latches on the underside of Laptop Tray Arms (D) to adjust the arms to fit your laptop. Place the laptop on Laptop Tray (C), and once adjusted, lock Laptop Tray Arms (D) to secure it in place.
  • Page 7 STEP 7 Remove the screws from the cable management covers on the underside of Arm (A) using the Phillips end of 4mm Allen Wrench (T-A). Route cables and reassemble the cable managment covers. STEP 8 Adjust the tilt of Arm (A) using 5mm Allen Wrench (T-B).
  • Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
