- Page 1 Dual Wall Mount Designed for Sonos One, One SL, Play 1 SKU: MOUNT-PLAY1B/W Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-play1b...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
Package Contents A (x2) B (x2) C (x2) Mount Support Cover Bracket Included Hardware & Tools S-A (x2) S-B (x2) W-A (x4) W-B (x4) M4x6mm M5x8mm ST5.5x50mm Concrete Screw Screw Screw Anchor T-A (x1) 4mm Allen Wrench Tools Needed: Phillips Pencil Level Drill... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Separate Mounts (A) into Wall Bracket (A1) and Support (A2). - Page 5 STEP 2 Option 1: Wood Stud Mounting Use the Wall Brackets (A1) and a pencil to mark mounting holes on the wall where a stud is located. Use of a stud finder and level is recommended. Pre-Drilling Instructions Drill mounting holes using illustration below. 5/32”...
- Page 6 Wood Stud Mounting - Cont’d Secure the Wall Brackets to the wall using ST5.5x50mm Screws (W-A) and a Phillips screwdriver. NOTE: Make sure the triangular cutout is on the top Do NOT use included Anchors (W-B) for wood or drywall. Press Covers (C) into the Wall Brackets.
- Page 7 Option 2: Concrete/Brick Wall Mounting Use the Wall Brackets (A1) and a pencil to mark mounting holes on the wall. Use of a level is recommended. Pre-Drilling Instructions Drill mounting holes using illustration below. 5/16” (8mm) Drill Bit 2.4” (60mm) Hole Depth...
- Page 8 Concrete/Brick Wall Mounting - Cont’d Press Concrete Anchors (W-B) into the drilled holes. Secure the Wall Brackets to the wall using ST5.5x50mm Screws (W-A) and a Phillips screwdriver. Press Covers (C) in to the Wall Brackets. NOTE: Make sure the triangular cutout is on the top Press Covers (C) into the Wall Brackets.
- Page 9 STEP 3 Route the speaker power cables through the slots in the Supports (A2), and place the speakers on the Supports. Secure Support Brackets (B) to the Supports using M4x6mm Screws (S-A) and a Phillips screwdriver. Do not over-tighten.
- Page 10 STEP 4 Insert the Metal Rods on Supports (A2) into the Wall Brackets (A1). Secure using M5x8mm Screws (S-B) and a Phillips screwdriver. Metal Rod STEP 5 Adjust the tilt by adjusting the screws located on the side of the Mount (A) using 4mm Allen Wrench (T-A).
- Page 11 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK ]...
-
Page 12: Last Updated
LAST UPDATED: 7/02/24 REV2 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
