General Information
INSTALLATION CONSIDERATIONS
This section covers some of the more common installation issues seen by a service technician. An improper instal-
lation, though not a valid service issue, has the potential to lead to a customer placing a call for service. Installation
related customer complaints could include, but are not limited to: Unit leveling, unit movement, door misalignment,
doors and drawers not sealing, internal frost or condensation, warm compartment temperatures, exterior condensa-
tion, etc.. .
NOTE: If additional installation information is needed, refer to the complete Installation Manual, or contact the Sub-
Zero Technical Assistance Department.
UNIT COULD TIP FORWARD UNDER CERTAIN LOAD CONDITIONS. FAILURE TO INSTALL ANTI-TIP COM-
PONENTS AND EXTEND LEVELERS TO THE FLOOR ACCORDING TO INSTALLATION MANUAL COULD
RESULT IN SERIOUS PERSONAL INJURY OR DEATH.
Unit Leveling
NOTE: The kickplate/grille must be removed before
leveling (See Figure 2-1).
anchored to the cabinets, the side molding strips must
be removed and the anchor screws must be extracted
from the unit to cabinet brackets before leveling
Figure 2-2). These components must be reinstalled
after leveling.
Figure 2-1. Kickplate/Grille Removal
To level the unit, turn the front leveling legs counter-
clockwise to raise the front or clockwise to lower it. To
assist in turning the front leveling legs up or down, use
a standard straight-blade screwdriver and place it in the
foot of the front leg, then rotate the leveler foot in the
desired direction (See Figure 2-3).
#7015817 - Revision A - January, 2010
INTEGRA TED
INTEGRA TED
If the unit has already been
(See
Kickplate / Grille
(736 T (736 T all SWS #2970000) all SWS #2970000)
Figure 2-2. Side Molding & Bracket
Figure 2-3. Adjusting Front Levelers
2-2
SERIES
SERIES
