Sub-Zero INTEGRATED Series Service Manual page 2

General Information
INTRODUCTION
This Technical Service Manual has been compiled to provide the most recent service information for 736 Series Tall
units, starting with Serial #2970000. This information will enable the service technician to troubleshoot and diagnose
malfunctions, perform necessary repairs, and return a unit to proper operational condition.
The service technician should read the complete instructions contained in this manual before initiating any repairs.
IMPORTANT SAFETY INFORMATION
Below are the Product Safety Labels used in this manu-
al. The "Signal Words" used are
TION.
When reviewing this manual, please note these differ-
ent Product Safety Labels placed at the beginning of
certain sections of this manual. You must follow the
instructions given in the boxes below the Product
Safety Labels in order to avoid personal injury and/or
product damage.
The sample Product Safety Labels below illustrate the
precautions that should be taken when the signal word
is observed.
INDICATES THAT HAZARDOUS OR UNSAFE
PRACTICES COULD RESULT IN SEVERE PERSON-
AL INJURY OR DEATH
Indicates that hazardous or unsafe practices could
result in minor personal injury or product and/or
property damage
In addition, please pay attention to the signal word
"NOTE", which highlights information that is especially
important for the topic being covered.
This manual was designed to be used by Authorized Service Personnel only. Sub-Zero, Inc. assumes no
responsibility for any repairs made on Sub-Zero refrigeration units by anyone other than Authorized
Service Technicians.
The information and images contained in this manual are the copyright property of Sub-Zero, Inc. Neither this man-
ual nor any information or images contained herein may be copied or used in whole or in part without the express
#7015817 - Revision A - January, 2010
INTEGRA TED
INTEGRA TED
WARNING or CAU-
written consent of Sub-Zero, Inc. ©, all rights reserved.
(736 T (736 T all SWS #2970000) all SWS #2970000)
TECHNICAL ASSISTANCE
If you should have any questions regarding the 736
Series starting with Serial #2970000 and/or this manual,
please contact:
ATTN: Service Department
Madison, WI 53744 - 4988
Customer Assistance
Phone #: (800) 222 - 7820
Facsimile #: (608) 441 - 5887
Technical Assistance
(For Technicians in Customer's Homes Only)
Phone #: (800) 919 - 8324
Phone #: (800) 332 - 9513
Facsimile #: (608) 441 - 5886
Service Department e-Mail Address:
customerservice@subzero.com
7:00 AM to 6:00 PM Central Time
Monday through Friday
1-2
