Sub-Zero INTEGRATED Series Service Manual page 105

INTEGRA
INTEGRA
P/N 7010912
WIRING SCHEMATIC
MODEL: 736TFI
(After Serial #2970000)
LOW VOLTAGE
J5
0
PIN 1
0
E2 E7 E10 E6
J3
PIN 1
J2
0
HIGH VOLTAGE
BLACK
WHITE
J5
J7
E2 E7 E10 E6
J4
J3
J1
J2
ORANGE/BLACK
ORANGE
DOOR
LIGHT SWITCH
ORANGE/BLACK
ORANGE/BLACK
DRAWER
LIGHT
SWITCHES
TED
TED
(736 T (736 T all SWS #2970000) all SWS #2970000)
DISPLAY
J6
0
PIN 1
PIN 1
J7
PIN 1
0 J4
PIN 1
PIN 1
J1
0 0
L1 115 VOLTS
NEUT
60 CYCLES
GRAY
J6
PURPLE
TAN
ORANGE/BLACK
PINK
GRAY/WHITE
DEFROST
BLUE TERMINATOR
LIGHT
ORANGE TERMINATOR
ORANGE/BLACK
WHITE/BLUE
SERIES
SERIES
MEMBRANE SWITCH
BLUE/BLACK
BROWN
BLUE
BROWN
WHITE
RED
FREEZER
FAN SWITCH
CONDENSER
FAN MOTOR
PURPLE
M
FREEZER
OVERLOAD
PROTECTOR
M
3
PURPLE RED/BLACK
1
4
FREEZER
FAN CONTROL
RELAY
2 6
7 8
TAN
ICEMAKER
30-38 Ω
155-175 Ω
2300-2900 Ω
10-7
Wiring Information
-This wiring information is provided for use by qualified
service personnel only.
-Disconnect appliance from electrical supply before
beginning service.
-Be sure all grounding devices are connected when
service is complete.
-Failure to observe the above warnings may result in
severe electrical shock.
FZR EVAP
THERMISTOR
FZR CAB
THERMISTOR
FREEZER
FAN MOTOR
RED/BLACK
M
RUNNING
CAPACITOR
FREEZER
(WHEN USED)
COMPRESSOR
STARTING RELAY
WHITE
WATER VALVE
160 Ω
DEFROST
HEATER
DRAIN TROUGH
HEATER
DOOR
LIGHTS
DRAWER
LIGHTS
FILL TUBE
HEATER
#7015817 - Revision A - January, 2010
