Summary of Contents for Uplus Lighting IP MATRIX 5
- Page 1 User manual IP MATRIX 5 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3-4 Technical Specifications……………………………………………………………………………4 Control Menu …………………………………………………………………………………………4 DMX Channels ………………………………………………………………………………………5-7 Trouble Shooting……………………………………………………………………………………8 Fixture Cleaning………………………………………………………… …………………………8 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Display: DMX display Function DMX addr DMX address setting chan Mod DMX channel mode option:6/7/21/30 06CH workMod work mode: DMX,auto DMX512 AutoSP Auto mode speed setting MENU M/S mod master/slave setting, set Master for master unit, set SLAVE for DMX and slave unit Slave Dimm mod... - Page 6 137-153 green+white 154-170 blue+white color 171-187 red+green+blue 188-204 red+green+white 205-221 red+blue+white 222-238 green+blue+white 239-255 red+green+blue+white DMX Channels(7 channels) Channel Function Value 0-255 instruction master dimmer 0-255 master dimmer 0-100% 0-255 red dimmer 0-100% green 0-255 green dimmer 0-100% blue 0-255 blue dimmer 0-100% white 0-255...
- Page 7 DMX Channels(30 channels) Channel Function Value 0-255 instruction LED 1 master dimmer 0-255 LED 1 master dimmer 0-100% LED 1 red dimmer 0-255 LED 1 red dimmer 0-100% LED 1 green dimmer 0-255 LED 1 green dimmer 0-100% LED 1 blue dimmer 0-255 LED 1 blue dimmer 0-100% LED 1 white dimmer...
-
Page 8: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
