OneAdvisor High-Speed Network Testing Platforms
QUICK CARD
Tap to display the SLA Throughput
4.
screen.
► Enter the Committed Information Rate
(CIR).
► If the you are testing at full line rate or if
traffic is not being policed, uncheck the
Policing checkbox.
Tap the
5.
SLA Performance screen.
►
Enter the Frame Loss Ratio, Frame Delay,
and Delay Variation pass/fail criteria.
Tap the
6.
J-QuickCheck screen.
OneAdvisor High-Speed Network Testing Platforms
button twice to display the
button 5 times to display the
Figure 7: SLA Throughput
VIAVI//Public
Figure 8: SLA Performance
Figure 9: J-QuickCheck
3
