OneAdvisor High-Speed Network Testing Platforms
QUICK CARD
C O N F I G U R E T E S T
► The following Information is needed to
configure the test:
• Frame Size
• VLAN ID, if VLAN tagging is used.
• Committed Information Rate (CIR)
• Pass/Fail Threshold for Frame Loss
Ratio, Delay, and Delay Variation (Jitter)
Tap the
1.
Local Network Settings 1 screen.
► Select the Frame Size you wish to
generate.
Tap to display the
2.
Local Network Settings 2 screen.
► If you are testing a VLAN, set
Encapsulation to VLAN and enter
the VLAN ID.
OneAdvisor High-Speed Network Testing Platforms
button to display the
Figure 5: Local Network Settings 1
Figure 6: Local Network Settings 2
