Extended Result Codes. If the extended result codes configuration option is enabled, EC is added to the
following result codes:
5
CONNECT 1200
10 CONNECT 2400
11 CONNECT 4800
12 CONNECT 9600
13 CONNECT 14400
14 CONNECT 19200
24 CONNECT 7200
25 CONNECT 12000
86 CONNECT 16800
40 CONNECT 300
55 CONNECT 21600
56 CONNECT 24000
57 CONNECT 26400
58 CONNECT 28800
59 CONNECT 31200
60 CONNECT 33600
CONNECT 45000
CONNECT 56000
EC is replaced by one of the following codes, depending on the type of error control connection:
Code
Error Correction
V42bis
LAP-M V.42 error control and V.42bis data compression
V42
LAP-M V.42 error control only
MNP5
MNP4 error control and MNP 5 data compression
MNP4
MNP 4 error control only
NoEC
No error control protocol
Chapter 5 - AT Commands
86
