General Configuration Commands

@CONFIG Configuration Menu
Unit:
Values:
Default:
The @CONFIG command starts the TA's internal configuration menus, which you can then
use to customize the TA's configuration for your particular application. AT@CONFIG<CR>
must be entered while in a communication program's terminal mode--it cannot be given as an
extra command to a non-terminal application. There is help information in the configuration
menu and there are also on-screen instructions. The ESCAPE key can be used in place of
typing "X" or "EXIT" to exit the configuration menu. When finished configuring the TA, upon
exiting a prompt will ask whether or not the configuration is to be saved. A "y", "Y", "n", or
"N" is required as input. A "y" or "Y" will save the configuration (same as the &W0
command). An "n" or "N" will not save the configuration nor will it undo any changes made
while in the configuration menu. If there was a previous profile saved and changes were made
by mistake and are to be undone, then give the TA the AT*FS1<CR> command or turn off the
TA and turn it back on. The previous stored profile will be restored upon reset or power-up.
En Command Mode Echo
Values: n = 0 or 1
Default: E1 (Echo on)
When you enter commands, the TA echoes the characters back to the computer or terminal
where they appear on the monitor. This command turns this feature on and off.
E0
E1
%En Escape Sequence Options
Values: n = 0–5
Default: %E1 and %E4
By default, the modem responds only to the +++ escape method. However, you can use the
%E command to set the modem to respond only to the <break> method, to respond to either
+++ or the <break> method, or to ignore both methods and not escape. If the escape method
is enabled (not %E0), then the escape response (OK) is given if enabled by %E5. For
example, %E1 %E5 enables the "+++ escape method and OK response to "+++".
%E0
%E1
%E2
%E3
%E4
%E5
%E1 %E5
%E3 %E5
n/a
n/a
n/a
Echo off
Echo on
Modem won't escape
+++ escape method
<BREAK> escape method
Both +++ and <BREAK> escape methods
Disable OK response to +++
Enable OK response to +++
Enable +++ method and OK response to +++
Enable +++ or <BREAK> method and OK response to +++
