3.7
Installing ISIHx TAs & Modems to COM Ports in Windows NT
Install terminal adapters:
1.
In the Control Panel, double-click the Modems icon.
2.
The Modem Properties dialog box appears. Click Add.
3.
The Install New Modem dialog box appears. Check the box marked "Don't detect my modem; I will select
it from a list" and click Next.
4.
The Install New Modem dialog box appears. In the Manufacturers list, highlight "MultiTech Systems." In
the Models list, select an ISDN protocol then click Next. The valid choices are:
ISIHI_HP Auto-Protocol
ISIHI_HP PPP async
ISIHI_HP V.120 async
5.
The Install New Modem dialog box appears. Select the ports that correspond to:
•
the first two ports of the ISIHP-1S card
•
the first four ports of the ISIHP-2S/2U card
•
the first eight ports of the ISIHP-4S/4U/4SD
Any ports that existed prior to installing the ISIHP appear first in the list of available COM ports. Click
Next. The terminal adapters (the screen describes them as "modems") will be installed to the selected
COM ports.
6.
After the terminal adapters install, click Finish to return to the General tab to view COM port assignments
(and make changes if necessary). Now you are ready to install the modems.
ISIHI_HP Auto-Protocol CallBack
ISIHI_HP V.110 async
ISIHI_HP X.75 async
Chapter 3 - Software Installation
32
