Sending a Fax, Server Perspective – Acme99 Sends a Fax
6
Customer receives
Mary's FAX message
about product
specifications.
Acme99 Office
Pete
Email:pete
@acme99
.com
PBX Ext 3049
Pat
Admin
Multi-Tech Systems, Inc.
Customer's
Office
Station Ports
POTS
Modem
FF200
FaxFinder
Server
3 Mary's FaxFinder
Client SW communicates
with the FF200 over
Acme99's Ethernet
network.
PBX Ext 3033
PBX Ext 3031
Mary
Email:pat
@acme99
.com
Mary prints to FaxFinder
1
to fax product specifications
to a customer.
2 FaxFinder client SW captures
word processor output and
assembles outgoing message
from FF Client screens and
cover page.
FF200 FaxFinder Fax Server Admin User Guide
