Logging In (I); Setting Faxfinder Ip Addresses - Multitech FaxFinder FF110 Quick Start Manual

Multi-Tech FaxFinder Quick Start

2. Logging In (I)

a. Bring up a Web browser on your pc. At the browser's address
line, type the default Gateway address: http://192.168.2.1 and
press Enter.
b. The Login screen will appear.
At this point you can be assured that the FaxFinder is connected
to the network.
If the Login screen does not appear, see item #1, "What if I
can't see the web page for my FaxFinder?" in the
Troubleshooting section of the Administrator User Guide.
c. At the Login screen, enter admin (all lower case) in the User
Name field.
d. Enter admin (all lower case) in the Password field.
e. Click the Login button. The Web Management Home screen
will appear. From this screen, you can access all of the
FaxFinder Server software screens.

3. Setting FaxFinder IP Addresses

a. In the FaxFinder Administration screen, go to the IP
Configuration fields.
Administration: IP Configuration
192.168.4.89
IP Address
255.255.255.0
Subnet Mask
192.168.11.251
Name Server
update
b. Fill in the IP information that applies to your FF110 FaxFinder
Server unit. The fields for "IP Address," "Subnet Mask," "Default
Gateway" and "Name Server" are required. A "Secondary
Name Server" may be considered optional.
c. Click Update.
Server Installation
Default Gateway 192.168.4.1
Secondary
Name Server
11
