Technical Specifications - Multitech CC1600-11L User Manual

1.3

Technical Specifications

Rack Capacity
Connectors
Dimensions
Weights
Power Supply Input
Power Consumption
Ambient Temperature
Indicators
Up to 16 modems
IEC 320 Inlet Power Connector
19" wide x 7" high x 15" deep
48.26cm wide x 17.8cm high x 38.1cm deep
Rack with one power supply: 21lbs. (9.5 kg)
Rack with two power supplies and 16 modems: 30 lbs. (13.6 kg)
PS1600 - 90 to 245 Volts AC, 2.0 Amps
PS1648 - -40 to -56 Volts DC, 2.5 Amps
70 watts, for a fully loaded rack
32° to 120° F (0° to 50° C)
One LED per power supply
Chapter 1 - Introduction
7
