Technical Specifications

The MT9234ZBA-Series modem meets the following specifications:
Trade Name
Model Number
Server-to-Client
Client-to-Server
Client-to-Client
Data Rates
Fax Data Rates
Voice Compatibility
Data Format
Modem Compatibility
Fax Compatibility
Video Compatibility
Error Correction
Data Compression
Speed Conversion
Mode of Operation
Flow Control
Intelligent Features
Command Buffer
Transmit Level
Frequency Stability
Receiver Sensitivity
AGC Dynamic Range
Interface
Connectors
Cables
Diagnostics
Indicators
Speaker
Operating
Temperature
Power Requirements
Power Consumption
Approvals
Dimensions
Weight
Limited Warranty
Multi-Tech Systems, Inc. MT9234ZBA-Series User Guide (S000387D)
Downloaded from Elcodis.com electronic components distributor
®
MultiModem ZBA
MT9234ZBA or MT9234ZBAV
56K speeds when accessing a V.90 or V.92 server
Up to 48Kbps when accessing a V.92 server
33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800 bps,
14400, 12000, 9600, 7200, 4800, 2400, 1200, 0-300 bps
33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800
TIA/EIA IS-101 (Voice Option only)
Serial, binary, asynchronous
ITU-T V.92, V.90, V.34 enhanced, V.34, V.32bis, V.32, V.22bis, V.22; Bell 212A and
103/113; ITU-T V.21 & V.23; V.42, V.42bis, V.44.
ITU-T "Super" Group 3; Class 1.0, 2.0, 2.1; T.4; T.30; V.21; V.27ter; V.29; V.34; V.17; and
TIA/EIA Class 1, 2; TR29.2
ITU-T V.80 for H.324 video conferencing
ITU-T V.42
ITU-T V.44 (6:1 throughput)
Serial port data rates adjustable to 300, 1200, 2400, 4800, 9600, 19,200, 38,400, 57,600,
115,200, and 230,400 bps
Fax online modes; full duplex over dial-up lines
XON/XOFF (software), RTS/CTS (hardware)
Plug and play; fully AT command compatible; dialing options, autoanswer; adaptive
answer; EIA extended automode; adaptive line probing; automatic symbol and carrier
frequency during start-up, retrain, and rate renegotiation; DTMF detection; call status
display, auto-parity and data rate selections; keyboard-controlled modem options; non-
volatile memory; remote configuration; DTR dialing; callback security; A-law support in
56K modes; 11-bit support; real-time fax compression conversion; U.S. Caller ID
reporting; quick-connect startup (V.92).
40 characters
-12 dBm (Eruo/NAM) – varies by country/region setting
±0.01%
-43 dBm under worst-case conditions
43 dB
TIA/EIA RS-232C/ITU-T V.24/V.28
DB25F RS-232C connector; 2 RJ-11 telephone jacks; power jack
Country-specific telephone; power cables; serial cable.
Note: Any cables connected to the computer should be shielded to reduce interference.
Power-on self test, local analog loop, local digital loop, remote digital loop.
LEDs for Transmit Data, Receive Data, Carrier Detect, Off Hook, Terminal Ready, Power.
Internal speaker for call progress monitoring.
0°– 50° C (32°–120° F) ambient under closed conditions;
humidity range 20–90% (non-condensing)
Global modems: 100–240 VAC, 50/60 Hz universal power supply
9 VDC, 300 mA maximum
CE Mark
EMC: FCC Part 15 Class B, EN55024, EN55022 Class B, ICES-003 Class B
Safety: UL/cUL 60950-1, IEC 60950-1, AS/NZS 60950
Telecom: 47CFR Part 68, CS03, TBR21, other countries also included
10.8 cm wide x 14.8 cm long x 2.9 cm high (4.25" x 5.8" x 1.15")
224 g (8 oz)
2 years
