White Triple Monitor Desk Mount
Instruction Manual
SKU: STAND-V103W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v103
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!
Advertisement
Related Manuals for Vivo STAND-V103W
Summary of Contents for Vivo STAND-V103W
- Page 1 White Triple Monitor Desk Mount Instruction Manual SKU: STAND-V103W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v103 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED 22 lbs DO NOT EXCEED WEIGHT CAPACITY. Per Arm Failure to do so may result in serious injury. (10 kg) Phillips Drill Screwdriver ASSEMBLY STEPS STEP 1 OPTION A: Clamp Installation Install Upper Clamp (C) to Pole (A) using M6x8mm Screws (S-A) and a Phillips screwdriver. - Page 4 STEP 1 (Continued) OPTION C: Self-Drilled Grommet Base Installation Drill a 3/8” (10mm) diameter hole through the mounting surface Remove adhesive backing from Grommet Pad (L) and place on the bottom of Pole (A). Install Pole (A) to existing grommet hole using Support Plate (I) with M10 Bolt (S-F), M10 Washer (S-E) and Lock Washer (S-G).
- Page 5 STEP 3 Assemble Arm (E) to Pole (A) using M8x10mm Screws (S-D) and 5mm Allen Wrench (T-B). STEP 4 OPTION A: Flat Back Monitor OPTION B: Curved Back Monitor Secure Side VESA Plates (K) to monitors Secure Side VESA Plates (K) to monitors using M4x12mm Thumbscrews (M-A).
- Page 6 STEP 5 Assemble side VESA Plates (K) with Assemble Center VESA Plate (J) with monitors to Arm Extensions (F). Secure monitor to Arm (E). Secure using using Cap Nuts (S-I). M4x6mm Screw (S-H). STEP 6 Remove the plastic covers on Arm Adjust the Tilt and rotation of the center Extensions (F) and adjust the tilt using monitor by loosening the set screw on...
- Page 7 STEP 7 Adjust the Height of Center Monitor: Adjust the Height of Side Monitors: Using 6mm Allen Wrench (T-C), turn the Remove Cap Nut (S-I) from Arm Exten- bolt on Arm (E) counterclockwise to sions (F). Turn the screw using counter- clockwise using 3mm Allen Wrench (T-A) lower the center monitor, turn the bolt clockwise to raise the center monitor.
