Teknion dna-SQUARE COFFEE TABLE Manual page 7

seating
Installation Guides
Section: SOFT SEATING
Description: dna-SQUARE COFFEE TABLE
FEED TRANSMITTER CABLE & PLUG CABLES
C5
C3
C2
NOTE: Reverse View
STEP 8: Feed Wireless Transmitter Cable inside the Metal Enclosure. Then connect cables with
Switcher
NOTE: Detail View
PLACE SWITCHER & TRANSMITTER ASSEMBLY
STEP 9: Place all devices into the Enclosure. Align Transmitter with hole on the side of Metal
Enclosure then fasten with Screws previously removed.
Date: Sep 2019 Page No: 7 of 10
